High Temperature battery ER26760S 3.6V 10.5 26-76-MR Li-SOCl2 Battery 165C degree for Oil Drilling device

High Temperature battery ER26760S 3.6V 10.5 26-76-MR Li-SOCl2 Battery 165C degree for Oil Drilling device

  • High Temperature battery ER26760S 3.6V 10.5 26-76-MR Li-SOCl2 Battery 165C degree for Oil Drilling device
  • High Temperature battery ER26760S 3.6V 10.5 26-76-MR Li-SOCl2 Battery 165C degree for Oil Drilling device
High Temperature battery ER26760S 3.6V 10.5 26-76-MR Li-SOCl2 Battery 165C degree for Oil Drilling device
Product Details:
Place of Origin: China
Brand Name: SER or OEM
Certification: CE,ROHS,UN38.3,MSDS
Model Number: ER26760S
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: 2.5USD App
Packaging Details: 500pcs per carton
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 150000pcs per month
Contact Now
Detailed Product Description
Size: φ26mm X H 76.50mm Nominal Capacity: 10.5Ah
Nominal Voltage: 3.6V Application: Downhole Oil & Gas MWD, LWD,Sensor System,Wireless And Military Equipment,Tracking System,Pipeline Inspection Gauge
Shelf Life: Up To 10 Years Terminal Type: Various Options Available
Chemistry: Lithium Thionyl Chloride Type: Spiral Type,Energy Type,Li/SocL2 Battery
Operating Teerature: -55---165 C Degree Package: Standard Package
Model Name: ER26760S Color: Black PVC
Self-Discharge Rate: Less Than 1% Per Year

High Temperature battery ER26760S 3.6V 10.5 26-76-MR Li-SOCl2 Battery

High Temperature battery,ER26760S,26-76-MR,Li-SOCl2 Battery,High Temperature battery 3.6V

Li-SOCL2 Batteries  Catalogue(图1)






High temperature Battery ER26760S Features:



Recommended battery model parameters:QQ截图20240422142509.jpg

Battery model: ER26760S LiSOCL2 battery

Battery brand: SER

Battery performance index

1. Battery capacity: (23±2℃, 100mA/2.0V) 10.5Ah

2. Open circuit voltage: ≥3.64V

3. Chemical Composition: Li-SOCl2

4. Continuous working currents: 100mA

5. Large pulse working current: 200mA

6. Operating temperature range: -40~+150℃

7. Battery storage life: 10 years

(Storange: clean, below +20℃, dry and ventilated.)

Available Terminations S:Standard Terminations Special Termination are aviable upon request T: Solder Tabs P:Axial Pins

ER26760S High temperature LiSOCL2 Battery Advantages









In the realm of high-temperature batteries, the ER26760S 3.6V 10.5Ah 26-76-MR Li-SOCl2 battery stands out as a remarkable innovation. This battery, with its unique chemistry and design, offers unprecedented performance in extreme heat conditions, making it a valuable asset for a wide range of industrial and military applications.



QQ截图20240422142520.jpgThe ER26760S battery's core strength lies in its Li-SOCl2 chemistry. Lithium sulfuryl chloride (Li-SOCl2) batteries are known for their high energy density, long shelf life, and ability to operate at temperatures well above those tolerable by traditional lithium-ion batteries. This makes them ideal for use in environments where temperatures can soar, such as in deserts or near engines and other heat-generating machinery.



The battery's 3.6V voltage and 10.5Ah capacity combine to provide ample power for even the most demanding tasks. The 26-76-MR dimensions ensure a compact and efficient form factor, allowing it to be easily integrated into various systems and devices.



What truly sets the ER26760S apart, however, is its resilience in high-temperature environments. It can operate safely and effectively even when exposed to temperatures far exceeding those of conventional batteries. This makes it a crucial component in applications where reliability and performance are paramount, such as in aerospace, oil and gas exploration, and defense systems.



In conclusion, the ER26760S 3.6V 10.5Ah 26-76-MR Li-SOCl2 battery represents a significant leap forward in high-temperature battery technology. Its superior performance and durability in extreme conditions make it a game-changer for industries that operate in challenging environments. As technology continues to evolve, it is likely that we will see even more innovations in this field, further expanding the possibilities for high-temperature applications.








Applications




Applications:

1. Petroleum Industry: Down hole high temperate EPG, flow meters, LWD/MWD, and other battery powered down hole

high temperature instruments ( processing and battery packs can be done as required)



2. Automobile industry: TPMS, Diesel engine cylinder monitor and so on.



3. Geothermic industry: High temperature inspection instruments



4. Military uses and other battery-powered devices used in high temperature












Why Choose US

SER was founded in 2004, as a leading primary lithium battery manufacturer and solution provider in China, we remain dedicated to leading the R&D and manufacturing of various types of primary lithium batteries.



We have first-class production equipment and high-quality raw materials. Our main products cover a wide range of varieties, such as Li-SOCl2 Cylindrical Batteries, Li-MnO2 Cylindrical Batteries, Lithium Pouch Cell, Ultra Pulse Capacitors.



Support OEM.

If you want a custom size & capacity of li polymer battery, it's also friendly for us.

Our experienced engineers and advanced technology will give you safe, excellent and fast design solution, giving your product a competitive edge over competitors.



What we offer:

1. Strictly quality control

2. First rate service

3. Professional technical advisory

4. Complete production base

5. Continuous supply guarantee



All we do what we want to help you to start your good idea.






Company Advantage




Li-SOCL2 Batteries  Catalogue(图6)   ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图2)   ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图3)

With three producing bases, sixteen

advanced manufacturing lines, over

1650 staff, we can produce 20000,00

primary cells and 600,000 rechargeable

battery packs per month.



Founded in 2004, Guangzhou Ser

Battery Technology Co.,Ltd is CE. UL.

SGS, IEC and ISO9001 certificated

High-tech company.



Customers' interests always goes

first,SER has a professional sales

team, shipping team and after

sales team to provide you with

the best solutions and timely service.


ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图4)   ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图5)   ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图6)

Efficient and innovative R & D team

helps the company lead in product

design and superior performance



While keeping core competitivenes,

SER also takes into account relevant

social, economic and environmental

goals, and always maintains sustained

profitability and development capabilities.

  For many years, the professional
SER team has focused on the lithium
battery industry, and has taken every
product as a work of art with firmness,
steadiness and excellence.






Product Advantage

1. Full range of battery categories

17 years of development, SER have
the ability to offer many product
categories:Lisocl2 Battery, LiMNO2
battery, LiPO battery and LiFePO4
batteries.



2. Safety

The perfect protection IC has been used,
undervoltage, short-circuit, overload,
backflow,and we have carried out strict
inspections and external tests, make sure
no quality problems in the hands of
customer.



3. Excellent and stable performance

Strict control for cleanliness in dust-free
workshop from IQC,IPQC to OQC, we
control every step strictly CE, UL, SGS,
FCC,ROHS and ISO9001: 2000 certified.



4. OEM & ODM Ability

Professional engineers have rich
experien ce in OEM& ODM. The
independent labs have many
sophisticated machines and design
softwares always guarantee our OEM
&ODM projects always keep in
high level.



5. Technology

Our dedicated and experienced engineers

team always work together to our customers
from their product design to battery solution
and mass production,Reduce their time cost
and communication cost.



6. Delievry

Fast delivery with standard package,will
bring you a professional experience with
long-term cooperative freight company
and stable routes.
